Backward compatible with TC22/TC27 accessories Reuse existing batteries, charging cradles and accessories β protecting your investment and simplifying migration to the TC2.
Built for the frontline β faster, tougher and more connected than ever before.
Qualcomm Dragonwing Q-6690 processor up to 2.0 GHz with 6 or 8 GB RAM. Run all your apps simultaneously without compromise.
The fastest wireless connectivity available. Wi-Fi 7 doubles speed over Wi-Fi 6; 5G 3rd Gen Release 17 keeps workers connected anywhere in the world.
FIPS 140-3 and Common Criteria certified. Lifeguard for Android, facial recognition via Identity Guardian, and optional Secure Element on select SKUs.
IP68 and IP65 sealed. Survives 6 ft. drops to concrete, 750 tumbles, and sub-zero temperatures to -4Β°F (-20Β°C) with Corning Gorilla Glass protection.
AC670 advanced-range scanner reads barcodes up to 100 ft. away. SR500 standard range for everyday workflows. Optional integrated UHF RFID reads 200 tags/sec.
User-removable Li-Ion battery (3800 mAh standard or 5200 mAh extended). Optional hot swap on select SKUs keeps workers running all shift long.
Available in LAN (Wi-Fi only) and WAN (5G + Wi-Fi) variants, with standard or advanced-range scanners and 6 GB or 8 GB memory. Contact us for volume pricing.
Wi-Fi 7 only (no cellular). SR500 standard-range 1D/2D scanner. Standard 3800 mAh battery. Ideal for indoor environments with good Wi-Fi coverage.
5G + Wi-Fi 7 connectivity with SR500 standard-range 1D/2D scanner. Standard 3800 mAh battery. The most popular configuration for retail, logistics and field service.
Wi-Fi 7 with AC670 advanced-range scanner β reads barcodes up to 100 ft. and captures high-resolution colour images. Ideal for large warehouses and retail spaces.
5G + Wi-Fi 7 with AC670 advanced-range scanner. The premium field-ready configuration β scan from distance, capture images, and stay connected anywhere.
High-performance 8 GB config with enterprise security. Includes Secure Element IC and 8-pin back I/O for advanced integration. Ideal for regulated industries.
Top-spec TC201 β 8 GB RAM, hot swap battery for zero-downtime operation, Secure Element security and 8-pin back I/O for mission-critical all-shift deployments.
All specifications shown are for the TC201 ROW (Rest of World) SKUs. Contact us to confirm specifications for your specific configuration.
| Processor | Qualcomm Dragonwing Q-6690, up to 2.0 GHz |
| Operating System | Android with Lifeguard for Android support |
| RAM / Storage (Standard) | 6 GB LPDDR5 RAM / 64 GB UFS 2.2 Flash |
| RAM / Storage (Advanced) | 8 GB LPDDR5 RAM / 128 GB UFS 3.1 Flash |
| Memory Expansion | MicroSD user-accessible, up to 2 TB |
| SIM | 1x Physical SIM + Dual eSIM (WAN SKUs) |
| Performance vs Legacy | Up to 150%+ faster than TC21/TC26/TC22/TC27 |
| Lifecycle Support | Lifeguard for Android β extended OS update support |
| Display | 6.0 inch Full HD+ (2160 x 1080), LED backlit, 450 NITS |
| Glass | Corning Gorilla Glass on display and scanner exit window |
| Touch | Multi-mode capacitive; bare or light gloved; water droplet rejection |
| Rear Camera | 16 MP auto-focus with controllable LED flash |
| Front Camera | 5 MP fixed focus |
| Scan Engine (Standard Range) | SR500 1D/2D β high-visibility yellow LED aimer |
| Scan Engine (Advanced Range) | AC670 1D/2D β barcodes up to 100 ft.; high-res colour image capture |
| RFID (optional, select SKUs) | Integrated UHF RFID; up to 3.94 ft.; 200 tags/sec; EPC Class 1 Gen2 |
| Wi-Fi | Wi-Fi 7 (802.11be), tri-band 2.4/5/6 GHz, 2x2 MU-MIMO, MLO simultaneous multi-band |
| Cellular (WAN SKUs) | 5G 3rd Gen Release 17, Sub-6 GHz NSA/SA, LTE-A, Dual SIM / Dual Standby |
| Bluetooth | Bluetooth 6.0, Class 1 and 2, 2x2 Tx, BLE Audio 5.3 |
| GPS (WAN SKUs) | GPS, GLONASS, Galileo, BeiDou, QZSS; Dual-band GNSS |
| NFC | ISO 14443 A&B, Mifare, FeliCa; Apple/Google Wallet; EMVCo |
| Voice | VoLTE, VoNR, VoIP, PTT, HD Voice; AI-based echo and noise suppression |
| Ports | USB Type-C (USB 3.1) front; 2-pin or 8-pin back I/O (model dependent) |
| Notifications | Audible tone, multi-colour LEDs, vibration |
| Sealing | IP68 and IP65 per IEC 60529 |
| Operating Temperature | -4Β°F to +122Β°F (-20Β°C to +50Β°C) |
| Drop Rating | 6 ft. (1.83 m) to concrete at room temperature; exceeds MIL-STD-810H |
| Tumble Rating | 750 tumbles at 1.6 ft.; 750 tumbles at 3.3 ft. with rugged boot |
| ESD | Β±15 kV air discharge, Β±8 kV direct and indirect |
| Security | FIPS 140-3 Validated (ISO 19790); Common Criteria (ISO 15408); Secure Boot; Verified Boot |
| Certifications | Android Enterprise Recommended (AER); Google ARCore; Wi-Fi CERTIFIED 7 |
| Warranty | 1 year from date of shipment |
The TC201 adapts to the demands of retail, logistics, warehousing and field service environments.
Order picking, assisted selling, mobile POS, line busting, inventory counts, price and stock checks, and Click & Collect.
Picking, put-away, shipping/receiving, asset management, inventory control and production management.
Last-mile delivery, proof of delivery, route accounting, asset tracking and scheduling/location-based services.
Route optimisation, invoicing, document capture and location-based task management for field-based workers.
Contact our team for expert advice, a demo or a tailored quote. As a Zebra Advanced Business Partner, we can help you choose the right configuration and accessories for your operation.
